Using Templates to Acquire Images
KODAK RVG Digital Radiography Systems User’s Guide (CS4000_en) 3–3
Using Templates to Acquire
Images
Use a Full Mouth Series (FMS) to track and acquire
digital intraoral radiographic images. The templates
consist of boxes corresponding to a region of the
mouth with a preview frame displaying an enlarged
view of the selected image.
The templates are based on the type of sensor you are
using and the region of the mouth you are targeting.
If you select a Size 1 frame but try to insert a Size 2
image, the Size 2 image is inserted in the next free Size
2 frame.
Table 3–1 shows the sensor size and image type for
each template.
Table 3–1 Template Descriptions
Template
Sensor
Size
Image Type
RVG FMS #1
Size 1
Vertical PA images
RVG FMS #2
Size 1
Size 2
All Size 1 and Size 2 images
RVG FMS #3
Size 1
Size 2
All Size 1 vertical images; Size 1
and Size 2 bitewing images
RVG FMS #4
Size 1 Anterior images
Size 1
Size 2
Posterior images
Size 1
Size 2
Bitewing images
RVG FMS #5
Size 1 Bitewing images or PA images
RVG
Bitewing
format
Size 1 Four bitewing images
Size 2 Four bitewing images
Note
If you select an image
other than Size 1, it is
not inserted into the
RVG FMS #1; it is
opened in a single
window.
