Kohler 6VSG Service Manual

TP-6844 1/13 Section 3 Controller 33
Genset Run Time Genset Controller Date Format MM/DD/YYYY
or
DD/MM/YYYY
MM/DD/
YYYY
Genset Run Time Genset Controller Time Format 12 or 24 hr 12 Hr
Genset Run Time Genset Date Time of Next Maintenance Read Only N/A
Genset Run Time Maintenance Period In Days days Read Only 365
Genset Run Time Maintenance Period Remaining s Read Only 31536000
Genset Run Time Genset Controller Clock Time Zone Offset Read Only 1/1/01
12:00:00
AM
Genset Personality Profile ECM Model DO NOT
CHANGE
No ECM
Genset Personality Profile Engine Number Of Flywheel Teeth Locked 12
Genset Personality Profile Engine Warmed Up Temperature °C/F 77–140°C 90°C
Genset Personality Profile Engine Cooled Down Temperature °C/F Locked 102°C
Genset Personality Profile Engine Crank Disconnect Speed rpm 300–1000 750
Genset Personality Profile Engine Idle Speed rpm 600–3000 2200
Genset Personality Profile Engine Run Speed rpm 1000–3900 2900
Genset Personality Profile Personality Installed Options None or 6VSG
Telecom for
comm. kit
6VSG:None;
Comm Kit: 6VSG
Telecom
Genset System Configuration Genset System Voltage V 24–60 24V = 27
36V = 40.5
48V - 54V
Genset System Configuration Genset Power Rating kW DO NOT
CHANGE
Auto select based
on genset model
and fuel type
Genset System Configuration Genset Rated Current A Read Only
Genset System Configuration Genset System Battery Voltage V 12/24 12
Genset System Configuration Current Transformer Ratio Locked 400
Genset System Configuration Measurement System English or metric English
Genset System Configuration Display Contrast 0–100 50
Genset System Configuration Genset System Language % English English
Genset System Configuration Generator Maximum Percent Capacity % 0–120 85.0
Genset System Configuration Genset Fuel Type Natural Gas or
LPG (pulldown)
Natural Gas
Genset System Configuration Automatic Start Minimum Voltage V Read Only 37.5
Genset System Configuration Automatic Stop Minimum Percent Load % Read Only 40
Genset System Configuration Automatic Start Minimum Voltage Delay s Read Only 180
Genset System Configuration Automatic Stop Minimum Load Delay s Read Only 180
Genset Calibration Genset Calibration Factor Voltage L1-L2 0.9–1.1 1.0063
Genset Calibration Genset Calibration Factor Voltage L2-L3 0.9–1.1 0.9909
Genset Calibration Genset Calibration Factor Voltage L1-N 0.9–1.1 0.9427
Genset Calibration Genset Calibration Factor Current L1 0.9–1.1 1.000000
Genset Calibration Genset Calibration Factor Current L3 0.9–1.1 1.000000
Genset Calibration Current Transformer Calibration At No Load Read Only 3.7
Genset Calibration Current Transformer Calibration At Full Load Read Only 170.3
Advanced Speed Control Proportional Gain DO NOT
ADJUST unless
instructed by the
Kohler
Generator
Service
Department.
Factory set per
unit.
Advanced Speed Control Transient Integral Gain
Advanced Speed Control Derivative Gain
Advanced Speed Control Slow Correction Integral Gain
SiteTech Group Parameter Units
Adjustment
Range * Default Setting
