34 Section 3 Controller TP-6844 1/13
Voltage Regulator Voltage Regulator Average Voltage
Adjustment
V 24–64 (Auto
select with
system voltage)
27, 40.5, or 54
(System Voltage)
Voltage Regulator Voltage Regulator Volts Per Hertz Slope % 1–10 5
Voltage Regulator Voltage Regulator Gain 1–255 128
Engine Timing Engine Start Delay s 0–300 0
Engine Timing Engine Cool Down Delay s 300–600 300
Engine Timing Engine Crank On Delay s 10–30 15
Engine Timing Engine Crank Pause Delay s 1–60 15
Engine Timing Engine Number Of Crank Cycles 1–6 3
Genset Protection Genset Low Battery Voltage Warning Delay s Read Only 90
Genset Protection Genset High Battery Voltage Warning Delay s Read Only 10
Genset Protection Genset Low Battery Voltage Warning Limit % 80–100 100
Genset Protection Genset High Battery Voltage Warning Limit % 110–135 125
Genset Protection Genset Battery Low Cranking Voltage
Warning Delay
s Read Only 6
Genset Protection Genset Battery Low Cranking Voltage
Warning Limit
% Read Only 60
Engine Protection Engine Locked Rotor Shutdown Delay s 3 3
Engine Protection Genset Low Engine Speed Shutdown Limit % 75–95 85
Engine Protection Genset High Engine Speed Shutdown Limit % 105–120 115
Generator Protection Genset High Voltage Shutdown Delay s Read Only 2
Generator Protection Genset High Voltage Shutdown Limit % Read Only 120
Digital Input B1 † Digital Input B1 Value Read Only False
Digital Input B1 † Digital Input B1 Enabled True or False False
Digital Input B1 † Digital Input B1 Event See dropdown
list in SiteTech
PIM: None; (0)
Comm Kit: Fuel
Pressure Switch
Digital Input B2 † Digital Input B2 Value Read Only False
Digital Input B2 † Digital Input B2 Enabled True or False False
Digital Input B2 † Digital Input B2 Event See dropdown
list in SiteTech
PIM: None; (0)
Comm. Kit:
Intrusion Alarm
Switch
Digital Output B1 † Digital Output B1 Value Read Only False
Digital Output B1 † Digital Output B1 Event See dropdown
list in SiteTech
Generator
Running
Digital Output B2 † Digital Output B2 Value Read Only False
Digital Output B2 † Digital Output B2 Event See dropdown
list in SiteTech
Common Fault
Digital Output B3 † Digital Output B3 Value Read Only False
Digital Output B3 † Digital Output B3 Event See dropdown
list in SiteTech
Low Battery
Voltage Warning
Digital Output B4 † Digital Output B4 Value Read Only False
Digital Output B4 † Digital Output B4 Event See dropdown
list in SiteTech
PIM: Not in Auto
Warning;
Comm Kit: Low
Fuel Pressure
Warning
Digital Output B5 † Digital Output B5 Value Read Only False
SiteTech Group Parameter Units
Adjustment
Range * Default Setting
