TP-6694 7/1824 Section 1 Specifications and Features
Description
Relay
Output
Status/
Notice
Shutdown
Function
Warning
Function
Display Message
General Functions
Alarm horn silenced (Alarm Silence LED only) X
Alarm silence, auto only (NFPA 110) or always AlrmSilence: Auto Only or
AlrmSilence: Always
S No
Aux. inputs 0--5 VDC, 1 analog
(2 additional inputs available with I/O module option)
Aux Input Warning X X
Aux. inputs 0--5 VDC, 1 analog
(2 additional inputs available with I/O module option)
Aux Input Shutdwn X X
Auxiliary inputs, up to 3 digital
(2 additional inputs available with I/O module option)
Aux Input Warning X X
Auxiliary inputs, up to 3 digital
(2 additional inputs available with I/O module option)
Aux Input Shutdwn X X
Backup parameters loaded Backup Pars Status S No
Battery charger 1 communication loss Bat1CommLoss X
Battery charger 2 communication loss Bat2CommLoss X
Battery charger fault * (* does not apply to charger
GM87448)
Batt Chg Flt X
X
Battery charger identity conflict BatIdErr X
Battery charger parameter mismatch Param Mismatch X
Battery Fault Battery Flt X
Chicago code active Auto Locked Notice N X
Common fault (includes ])
Common Fault Shutdwn X N X
Common warning fault Common Warng X N X
Default parameters loaded Default Pars Warning X X
Emergency stop Emerg Stop Shutdwn X] X
Enclosure temperature: high shutdown Enclsr Temp: High Shutdwn X X
Engine cooldown (delay) active Eng Cooldown Notice N X
Engine start delay active Start Delay Notice N X
Engine started Engine Start Status S X
Engine stopped Engine Stop Status S X
EPS supplying load Emerg Pwr On Notice N X
File system error (controller fault) File Error Shutdwn X X
Generator running Gen Running Notice N X
Input/output (module option board) communication loss OB1 Com Loss X X
Internal failure Intern Error Shutdwn X X
Metering communication loss MeterCommLos Shutdwn X X
NFPA 110 alarm active NFPA Alarm Notice N X
Not in auto (master switch) Not In Auto Warning X X
Remote start Remote Start Status S X
System ready System Ready Status S X
System timer failed TimerErrorNotice N X
Generator Functions
AC sensing loss AC Sens Loss Warning X X
AC sensing loss AC Sens Loss Shutdwn X X
Alternator protection Alt Protect Shutdwn X X
Ground fault input * Ground Fault Warning X X
kW overload Total Power High Shutdwn X X
Locked rotor (failed to crank) Locked Rotor Shutdwn X X
Overfrequency Freq High Shutdwn X X
Overvoltage (each phase) Volts xx--xx High Shutdwn X X
Underfrequency Frequency Low Shutdwn X X
Undervoltage (each phase) Volts xx--xx Low Shutdwn X X
(Voltage) regulator communication loss RegCommLoss Shutdwn X X
* Function requires optional input sensors or kits or is engine ECM dependent on some generator set models.
[ ECM inputs are engine manufacturer dependent.
] The Common Fault Shutdown includes the items marked X] in the Shutdown Function column.
