Kohler ZCS series User Manual

TP-5660 11/984 Specifications
1.5 Standard Features
The standard features listed here are for the ZCS
contactor power switching device. Refer to the logic
controller operation and installation manual for
controller specifications. See List of Related Materials
in the Introduction section in this manual.
D Provided as a complete automatic transfer switch
with E33+ (solid state logic), S340+ (solid state
logic), or M340+ (microprocessor logic) controller
in various enclosures
D Meets UL and CSA standards
D Voltage ratings up to 600 vac
D Amperage ratings for Programmed Transition
Switches from 40 to 3000 amperes
D Amperage ratings for Standard Switches from
600 to 3000 amperes
D Switching device electrically and mechanically
interlocked
D Two-pole, three-pole and four-pole
D Four-pole—fully rated
D Can be operated manually when unpowered
D Two normallyopen (N.O.)and twonormallyclosed
(N.C.) main shaft auxiliary contacts
D Withstand and closing current ratings as shown
below.
1.6 Ratings
The following tables provide information on contactor
withstand and closing current ratings (WCR).
Figure 1-5 provides WCR when used with any
current-limiting fuse or any overcurrent protective
device. Figure 1-6 and Figure 1-7 provides WCR when
coordinated with specific manufacturer’s circuit
breakers or fuse types. Figure 1-6 has ratings for
480 V maximum and applyto both UL and CSA listings.
Figure 1-7 has ratings for 600 V maximum and apply to
a CSA listing only.
Withstand and Closing Current Ratings per UL 1008 and CSA *
U
L
1
0
0
8
When Used With Any
Current-limiting Fuse
When Used With Any Overcurrent
Protective Device (3 cycles)
U
L
1
0
0
8
S
w
i
t
c
h
R
a
t
i
n
g
M
a
x
.
F
u
s
e
S
i
z
e
Maximum Current (amps) Maximum Current (amps)
S
w
i
t
c
h
R
a
t
i
n
g
(amps)
M
a
x
.
F
u
s
e
S
i
z
e
(amps)
@ 480 VAC @ 600 VAC @ 480 VAC @ 600 VAC
Programmed Transition Models:
40 50 200,000 150,000 22,000 18,000
80 100 200,000 150,000 22,000 18,000
100 125 200,000 150,000 22,000 18,000
150 200 200,000 150,000 30,000 25,000
225 300 200,000 150,000 30,000 25,000
260 350 200,000 150,000 30,000 25,000
400 600 200,000 150,000 35,000 30,000
Standard and Programmed Transition Models:
600 750 200,000 150,000 50,000 42,000
800 1000 200,000 150,000 50,000 42,000
1000 1250 200,000 150,000 50,000 42,000
1200 1500 200,000 150,000 50,000 42,000
1600 2500 200,000 150,000 100,000 85,000
2000 2500 200,000 150,000 100,000 85,000
2500 4000 200,000 150,000 100,000 85,000
3000 4000 200,000 150,000 100,000 85,000
* UL 1008 listed at 480 vac and CSA listed at 600 vac.
Figure 1-5. Withstand and Closing Current Ratings
