TP-5660 11/98 Specifications 7
1.7 Application Data
See Figure 1-8 for application data including the range of wire sizes for the transfer switch’s power terminals.
AL/CU UL-listed Solderless Screw-type Terminals for External Power Connections
Switch
S
i
z
e
Normal, Emergency, and Load Terminals
Switch
S
i
z
e
Normal, Emergency, and Load Terminals
S
i
z
e
(amps)
Cables per Pole Range of Wire Sizes
S
i
z
e
(amps)
Cables per Pole Range of Wire Sizes
40 1 #14 AWG to #2 AWG 800 4 #2 AWG to 600 MCM
80--100 1 #14 AWG to 1/0 AWG 1000 4 #2 AWG to 600 MCM
150 1 #8 AWG to 3/0 AWG 1200 4 #2 AWG to 600 MCM
225 1 #6 AWG to 250 MCM 1600 Bus Bar Connection
260 1 #6 AWG to 350 MCM 2000 Bus Bar Connection
400 1 #4 AWG to 600 MCM 2500 Bus Bar Connection
600 2 #2 AWG to 600 MCM 3000 Bus Bar Connection
Figure 1-8. Application Data
