TP-5660 11/98 Installation 61
12. Follow the generator set manufacturer’s
instructions to adjust the generator output voltage
and frequency to match the nominal system
voltage and frequency shown on the transfer
switch nameplate if they are different. The
automatictransferswitchwilloperatecorrectlyonly
to the rated system voltage and frequency
specified on the nameplate.
13. Movethe generatorset masterswitchtotheAUTO
position.
14. Disconnect the emergency power source by
opening upstream circuit breakers or switches to
the transfer switch.
15. Connect the power switching deviceand controller
wiring harnesses together at the inline disconnect
plug.
16. Close and lock the transfer switch enclosure door.
17. Reconnect power sources by closing circuit
breakers or switches. The transfer switch may
signal the generator set to run for TDEC, if
equipped.
NOTE
Wheninitiallyapplyingpowertothetransferswitch,
the engine start contacts remain closed signalling
the generator to run until the ATS’s Time Delay
Engine Cooldown (TDEC), if equipped, ends.
Installation of the transfer switch’s power switching
device is complete. Close and lock the enclosure door.
6.6.2 Automatic Operation Test
Testthetransferswitch’sautomaticcontrolsystem. See
the logic controller operation and installation manual for
the test procedure.
6.7 Controller Setup
See the logic controller operation and installation
manual for controller startup and setup procedures.
6.8 Ensure Warranty Registration
The transfer switch seller must complete a Startup
Notification Form and submit it to the manufacturer
within 60 days of the initial startup date. A Startup
Notification Form is included with generator sets and
covers all equipment in the standby system. Standby
systems not registeredwithin 60 days of theinitial date
are automatically registered using the manufacturer’s
ship date as the startup date.
