Electrical Use and Machine Dimensions/Weight
Amps Amps
Ship Weight
GT361AC 12 15 1
30.1 (76.5) 25.7 (65.3) 16.9 (42.9) 180 (82)
GT361AHK 12 15 1
30.1 (76.5) 25.7 (65.3) 16.9 (42.9) 180 (82)
GT361LC 11.1 15 2
30.1 (76.5) 25.7 (65.3) 16.9 (42.9) 174 (79)
GT361LHK 11.1 15 2
30.1 (76.5) 25.7 (65.3) 16.9 (42.9) 174 (79)
GT364AC 6.5 15 2
30.1 (76.5) 25.7 (65.3) 16.9 (42.9) 180 (82)
GT364AHK 6.5 15 2
30.1 (76.5) 25.7 (65.3) 16.9 (42.9) 180 (82)
GT364LC 6 15 1
30.1 (76.5) 25.7 (65.3) 16.9 (42.9) 174 (79)
GT364LHK 6 15 2
30.1 (76.5) 25.7 (65.3) 16.9 (42.9) 174 (79)
GT561AC 18.6 30 1
30.1 (76.5) 25.7 (65.3) 30.7 (78) 228 (103)
GT561AHK 18.6 30 1
30.1 (76.5) 25.7 (65.3) 30.7 (78) 228 (103)
GT561LC 17.7 30 1
30.1 (76.5) 25.7 (65.3) 30.7 (78) 218 (99)
GT561LHK 17.7 30 1
30.1 (76.5) 25.7 (65.3) 30.7 (78) 218 (99)
GT564AC 9.5 15 1
30.1 (76.5) 25.7 (65.3) 30.7 (78) 228 (103)
GT564AHK 9.5 15 1
30.1 (76.5) 25.7 (65.3) 30.7 (78) 228 (103)
GT564LC 9.1 15 1
30.1 (76.5) 25.7 (65.3) 30.7 (78) 218 (99)
GT564LHK 9.1 15 1
30.1 (76.5) 25.7 (65.3) 30.7 (78) 218 (99)
GB561AC 18.6 30 1
42.3 (107.4) 31.1 (79) 17 (43.2) 207 (94)
GB561AHK 18.6 30 1
42.3 (107.4) 31.1 (79) 17 (43.2) 207 (94)
GB561LC 17.7 30 1
42.3 (107.4) 25.63 (65.1) 17 (43.2) 185 (84)
GB561LHK 17.7 30 1
42.3 (107.4) 25.63 (65.1) 17 (43.2) 185 (84)
GB564AC 9.5 15 1
42.3 (107.4) 31.1 (79) 17 (43.2) 207 (94)
GB564AHK 9.5 15 1
42.3 (107.4) 31.1 (79) 17 (43.2) 207 (94)
GB564LC 9.1 15 1
42.3 (107.4) 25.63 (65.1) 17 (43.2) 185 (84)
GB564LHK 9.1 15 1
42.3 (107.4) 25.63 (65.1) 17 (43.2) 185 (84)
GB1064AC 16.3 25 1
42.3 (107.4) 31.1 (79) 33.7 (85.6) 348 (158)
GB1064AHK 16.3 25 1
42.3 (107.4) 25.7 (65.3) 33.7 (85.6) 312 (142)
GB1064LC 15.4 25 1
42.3 (107.4) 25.7 (65.3) 33.7 (85.6) 312 (142)
GB1064LHK 15.4 25 1
42.3 (107.4) 25.7 (65.3) 33.7 (85.6) 312 (142)
GB1064RC &
RC214APV
18.1 30 1 42.3 (107.4) 25.7 (65.3) 33.7 (85.6) 335 (152)
GB1064RHK
& RC214APV
18.1 30 1 42.3 (107.4) 25.7 (65.3) 33.7 (85.6) 335 (152)
40.75 (103.5) 22.75 (57.8) 30.2 (76.6) 160 (73)
CA Power
Tier
Min Circuit
Max
Fuse/Breaker
W
D
H
Ship Weight #(kg)
RC214APV
Dimensions - inches (cm)
Model Number
