23. Turn off the breaker or disconnect the fuse that will service the machine.
24. Make all electrical connections to the electrical service in a manner that complies with
local code
Note:
• If two separate ice making machines (for example two GB1064 models stacked) are
installed the bin thermostats of both ice makers will need to be connected to the crusher.
• Ensure that the thermostat cable is not routed through the ice chute. Do not run the cable
through the same hole that the safety switch wire assembly and the motor control wire
assembly are run through.
Initial Start-Up
1. Ensure all electrical connections were made properly and turn on the electrical service.
Note: There is no on-switch, the machine will run when the ice-maker tells it to.
2. Adjust the bin thermostat to turn off the ice maker before the ice level is above the guard
screen.
3. Adjust the thermostats to shut off the ice maker approximately 1 minute after the ice contacts
the capillary tubes.
Note:
• If ice is allowed to collect above the screen it will not clear when the ice below is removed.
This condition will cause ice to pile up in the chute of the crusher and ultimately, damage
the ice maker
• The use of the bottom guard will reduce the effective volume of the bin
ICE CRUSHER OPERATION
With the crusher knob in the crushed position, ice falling from the ice maker will be directed by
the selector plate through the crusher mechanism and deposited into the left side of the bin.
The crusher motor is powered through a relay which is energized by the hot gas valve circuit of
the ice maker. The selector knob must be in the crushed position to close a switch and complete
the circuit to the motor. Additionally, the front panel safety switches must be depressed (covers
on) for motor operation.
With the crusher knob in the "CUBE" position, ice falling from the ice maker will bypass the crusher
mechanism and be dumped into the right side of the bin. The crusher motor will not be energized.
