Kold-Draft GB564AC - Parts List

new 60 Series Service Manual.rev. 06.01.16.docx - 59 –
PARTS LIST
Description
Model(s)
Part Number
Actuator Motor
GT361
102140901
Actuator Motor
GT561, GB561
102123801
Actuator Motor
GT364, GT564, GB564, GB1064
102123802
Actuator Motor Box Cover
GT36x
102143401
Actuator Motor Box Cover
GT56x, GB56x, GB106x
102137201
Actuator Motor Capacitor
GT361, GT561, GB561
102124101
Actuator Motor Capacitor
GT364, GT564, GB564, GB1064
102124102
Cam (Front)
All
GBR00969
Cam (Rear)
All
GBR00949
Cam Pin
All
102121001
Cam Shaft
GT36x
102141801
Cam Shaft
GT56x, GB56x, GB106x
GBR00942
Cam Shaft Bracket
All
GBR00937
Cam Shaft Shim Set
All
GBR00580
Compressor
GT361
102140701
Compressor
GT364
102141701
Compressor
GT561, GB561
102119128
Compressor
GT564, GB564
102119131
Compressor
GB1064
102119126
Condenser-Air Cooled
GT36xA
102141901
Condenser-Air Cooled
GT56xA
102101803
Condenser-Air Cooled
GB56xA, GB1064A
102101802
Condenser-Liquid Cooled
GT36Xl, GT56xL, GB56xL,
GB106xL
102102101
Contactor-Single Pole 120V Coil
GT361, GT561, GB561
102103501
Contactor-Single Pole 240V Coil
GT364, GT564, GB564, GB1064
102103601
Control Box Cover
GT36x
102142501
Control Box Cover
GT56x
102142601
Control Box Cover
GB56x, GB106x
102137301
Controller 1.8
All
102145901
Defrost Valve Body
GT56x, GB56x, GB106xA/L
102101001
Defrost Valve Body
GT36x, GB106xR
102100801
Defrost Valve Coil
GT361, GT561, GB561
102101101
Defrost Valve Coil
GT364, GT564, GB564, GB1064
102101201
Drain Pan
GT36x
102142201
Drain Pan
GT56x, GB56x, GB106x
102137801
Drain Tube
All
102120101
Drier
All
GBR02750
Drier ( GB1064R )ADD ON 04/12/13
GB1064R
102107101
Evap/Bin Temperature Probe Assembly
GT36x, GB56x, GB106x
102143901
Evap/Bin Temperature Probe Assembly
(Up to S/N 608887)
GT56x, GB56x, GB106x
102144001
Evap/Bin Temperature Probe Assembly
(Starting at S/N 608888)
GT56x, GB56x, GB106x
102144201
Evaporator "C"
GT36x
102142101
