Kold-Draft RC314APV SC200 - Error-Code Troubleshooting

ERROR-CODE TROUBLESHOOTING
-Before troubleshooting, first check the Control Board and verify your software Revision
Level (Rev. 1.1, 1.2, or 1.3)-
CODE:
FAULT CODE
INDICATES:
POSSIBLE CAUSE:
SOLUTION:
10>
(Rev. 1.1/1.2/1.3)
1. Bad Evaporator Probe
(shorted) or wiring.
2. Hot Gas Valve stuck open-
Cuber stuck in extended
harvest mode.
3. Bad Control Board.
4. Actuator Motor won’t raise
the Water Plate.
1. Repair/replace wiring or
replace Probe.
2. Pull down the Water Plate
and verify the Hot Gas
Valve closes after the
Water Plate closes.
Repeat, with power to the
Hot Gas Valve coil
disconnected. If Hot Gas
Valve does not close,
replace it.
3. Replace Control Board.
4. Replace Actuator Motor.
(Motor never raises Plate
to actuate Plate Switch,
so HGV stays open &
Evap temp rises > 120F.
Evaporator temp over 120F.
20>
(Rev. 1.1)
1. Cam Arm or Cam Pin is
broken.
2. Cam Spring disengaged or
broken.
3. Plate-Up Switch stuck open
or not actuating.
4. Over-freeze causing ice to
stick to water plate.
5. Silicone coating on Water
Plate worn away.
6. During harvest, the
Evaporator Probe is out of
adjustment (reads too
warm) or is defective.
7. Arms-Up Switch stuck
closed- Plate stays down.
8. Bin Probe is out of position
1. Replace Cam Arm or
Cam Pin.
2. Reinstall springs or
replace as needed.
3. Adjust switch actuator or
replace as needed.
Check to insure that the
Plate-Up switch actuates
before the Arms-Up
switch actuates.
4. Lower the short water
level probe, in 1/16”
increments, until cubes
have a pea-sized dimple
in the center.
5. Replace the Water Plate
if the factory coating is
severely warn and is
causing ice to stick to it.
Use a Food-Grade
Silicone spray to provide
a temporary improved
surface, until the water
plate can be replaced.
6. Adjust Evaporator Probe
colder (turn CW), or
replace if adjustment
does not help.
7. Free up, adjust or replace
stuck/shorted Arms-Up
Switch, or repair wiring.
8. Re-position or replace Bin
Probe.
Water Plate failed to close
after three consecutive
attempts.
(Rev. 1.2/1.3)
After 3 attempts to close,
machine goes into a 30-
minute shutdown, with the
Plate open. It will repeat this
routine (w/ the Plate closing
3 times & then a 30-minute
wait) four times, before going
out on Code 20.
The Code 20 LED will flash
as this routine is in process,
and then light solid after the
routine tries 4 times and
ends Code 20.
