Kolida K5 PLUS - Mode Check and Switching

K5 Plus GNSS
- 13 -
Indicator
Status
Meaning
POWER
on
Normal voltage, built-in battery 7.4v
blink
Low battery
Satellite
blink
Number of satellite locked, cycle once every 5 seconds
Bluetooth
off
Handheld disconnected
on
Handheld connected
Signal/data
blink
Static mode: flashing in accordance with the setting
sampling interval when recording data
on
Base or rover mode: built-in module receives strong signal
blink
Base or rover mode: built-in module receives weak signal
off
Base or rover mode: built-in module receives no signal
Table 2-1
§2.1.4 Mode check and switching
Mode check
In normal working mode, press power key once, there is voice message to
indicate current working status.
Mode switching
After power on receiver, use data collector to connect the receiver, then configure the
working mode and data link mode.
