Kolida K5 PLUS - Handheld Controller S10; Basic Introduction of the Handheld

K5 Plus GNSS
- 15 -
The meaning of the lights during self-check
Indicator
Status
Meaning
on
Receiver is performing the self-check
on
OEM board self-check is passed
off
OEM board self-check isn’t passed
on
GPRS/GSM module part self-check is passed
off
GPRS/GSM module part self-check isn’t passed
on
Internal radio module self- check is passed
off
Internal radio module self- check isn’t passed
Table 2-2
§2.2 Handheld controller S10
Figure 2-7
§2.2.1 Basic introduction of the handheld
Here takes S10 for example (If you want to know more about Getac controller,
please refer to the manual for Getac controller), appearance of S10:
