§2.3.2 Radio appearance
Figure 2-20
① Control panel ②SN number
§2.3.3 Radio interface and panel
Mainframe Interface: 5-pin jack for connecting GPS receiver and power supply
Figure 2-21 5-pin port
Antenna interface：For connecting the transmitter antenna
Figure 2-22 Antenna interface
1
2
