Maintenance - Section 40 OM4064 06/11
Page 40-8 Lubrication and Service
10 HOUR (DAILY) LUBE AND MAINTENANCE CHECKS (Continued)
Truck Serial Number______________________ Site Unit Number_______________ Date_______________
Hourmeter_____________ Name of Service Technician___________________________________
TASK COMMENTS CHECKED INITIALS
9. AIR CLEANERS - Check the air cleaner vacuum
gauges in the operator cab. The air cleaner(s) must
be serviced if the gauge(s) shows the following maxi-
mum restriction:
Komatsu SSA16V159 Engine:
. . . . . . . . . . . . . . . . 6.2 kPa (25 in.) of H
2
O vacuum.
Refer to Section C in the shop manual for servicing
instructions for the air cleaner elements. Empty the air
cleaner dust caps.
NOTE: After service, push the reset button on face of
gauge to allow the gauge to return to zero
10. CAB AIR FILTER - Under normal operating condi-
tions, clean every 250 hours. In extremely dusty con-
ditions, service as frequently as required. Clean the
filter element with mild soap and water. Rinse com-
pletely clean and air dry with a maximum of 275 kPa
(40 psi). Reinstall the filter.
11. FUEL FILTERS (Fuel Separators) - Drain water from
the bottom drain valve on each fuel separator.
12. AUTOMATIC LUBE SYSTEM -
• Check the grease reservoir; fill as required. Lube
Key “D”.
• When filling the reservoir, check the grease filter
indicator. Clean or replace the grease filter if the
indicator detects a problem.
• Inspect the system and check for proper
operation. Ensure the following important areas
are receiving adequate amounts of grease. Lube
Key “D”.
Steering Linkage
Final Drive Pivot Pin
Rear Suspension Pin Joints - Upper & Lower
Body Hinge Pins - Both Sides
Hoist Cylinders Pins - Upper & Lower
Anti-sway Bar - Both Ends
13. WINDSHIELD WIPERS AND WASHER FLUID-
Check the windshield wipers for excessive wear and
check the windshield washer fluid level.
To Next Page
