OM6009 8/11 Payload Meter III - Section 60
Page 60-11
Table 1: HAUL CYCLE DATA
Data Unit Remark
Truck # alpha-
numeric
Up to 22 characters can be stored in this field to identify the truck. Typically this field will be just
the truck number.
Haul Cycle Start Date/Time seconds Number of seconds from 1/1/70 to the start of the haul cycle, haul cycle starts when the meter
transitions from dumping to empty state after the previous haul cycle, download program con-
verts seconds into date and time for display
Payload tons Stored as metric, download program allows for conversion to short or long tons.
Number of Swingloads number The number of swingloads detected by the payload meter
Operator ID number This is a 4 digit number that can be entered by the operator at the start of the shift.
Warning Flags alpha Each letter represents a particular warning message about the haul cycle. Details are located on
pages 10 and 11.
Carry-back load tons The difference between the latest empty tare and the clean truck tare
Empty haul time seconds Number of seconds in the tare_zone and empty states with the truck moving
Empty stop time seconds Number of seconds in the tare_zone and empty states with the truck stopped
Loading time seconds Number of seconds in the loading state
Loaded haul time seconds Number of seconds in the maneuvering, final_zone and loaded states with the truck moving
Loaded stop time seconds Number of seconds in the maneuvering, final_zone and loaded states with the truck stopped
Dumping time seconds Number of seconds in the dumping state
Loading start time seconds Number of seconds from the start of the haul cycle to when the meter transitions from empty to
loading state
Dump start time seconds Number of seconds from the start of the haul cycle to the time when the meter switches from
loaded to dumping state
Loaded haul distance m Distance traveled while loaded
Empty haul distance m Distance traveled while empty
Loaded max speed km/h Maximum speed recorded while the truck is loaded
Loaded max speed time seconds Number of seconds from the start of the haul cycle to the time when the max speed occurred
Empty max speed km/h Maximum speed recorded while the truck is empty
Empty max speed time seconds Number of seconds from the start of the haul cycle to the time when the max speed occurred
Peak positive frame torque ton-meter Positive frame torque is measured as the frame twists in the clockwise direction as viewed from
the operator’s seat.
Peak frame torque time seconds Number of seconds from the start of the haul cycle to the peak torque, download program con-
verts to time for display
Peak negative frame torque ton-meter Negative frame torque is measured as the frame twists in the counter-clockwise direction as
viewed from the operator's seat.
Peak frame torque time seconds Number of seconds from the start of the haul cycle to the peak torque, download program con-
verts to time for display
Peak sprung load tons Peak dynamic load calculation
Peak sprung load time seconds Number of seconds from the start of the haul cycle to the peak instantaneous load calculation
Front-left tire-ton-km/h t-km/h Tire ton-km/h for haul cycle
Front-right tire-ton-km/h t-km/h Tire ton-km/h for haul cycle
Average rear tire-ton-km/h t-km/h Tire ton-km/h for haul cycle
Truck Frame Serial Number alpha The truck serial number from the nameplate on the truck frame
Reserved 1-10 number These values are internal calculations used in the continued development of the PLMIII system
and should be ignored
