Konica Minolta bizhub 421 Service Manual

3. PERIODIC CHECK
24
Field Service Ver.2.0 Mar. 2009
bizhub 501/421/361
3.4.3 Replacing the paper exit suction filter
A. Periodically replaced part/cycle
• Paper exit suction filter : Every 250,000 prints *1
: Every 225,000 prints *2
*1 501/421
*2 361
B. Procedure
1. Remove the screw [1] and then remove the paper
exit suction filter cover [2].
2. Remove the paper exit suction filter [1].
3. Reinstall the above parts following the removal
steps in reverse.
a0r5f2c001ca
[2]
[1]
[1]
50gaf2c019na
