12
IC-207
7. Data Capture Field Service Ver.2.0 Mar. 2009
7. Data Capture
If any fault is caused in relation with the printer, acquire the print job data for the fault analysis.
Capture data of up to 5 jobs can be saved. When new data is saved, oldest one is deleted.
Caution
To enable this function, following conditions should be met.
• Hard disk should have been installed in the main body printer (copier).
• [Administrator Settings] - [Security Settings] - [Security Details] - [Print Data Capture] should be
set to [Allow].
• [Administrator Settings] - [Network Settings] - [FTP Settings] - [FTP Server Settings] should be set
to [ON].
1.
Activate the service mode.
• (Refer to the steps 1 through 7 of "ADJUSTMENT
/ SETTING, 5. Starting and Finishing the Service
Mode".)
2.
Press [System2] - [Data Capture] and select
[ON]. Selecting [ON] saves the job data transmit-
ted from PC in the copier hard disk.
3.
Confirm the IP address of the copier.
4.
Connect the Windows PC and copier with the
Ethernet cable.
5.
Activate the command prompt, specify the IP
address of the copier and activate the FTP.
6.
Enter User and Password.
• User: capture
• Password: sysadm
To Next Page
