Understanding the Media Path
Understanding the printer’s media path will help you locate media misfeeds
1 Toner cartridge 6 Tray 3 (optional lower feeder
unit)
2 Output tray 7 Tray 2
3 Fuser unit 8 Laser
4 Duplex (magicolor 4650DN only) 9 Imaging unit
5 Tray 1 (Manual feed tray) 10 Transfer belt unit
321
9
10
5
4
8
7
6
