5 Transportation, storage
5.1 Scope of delivery
Example for Total TA1
Data reading command to BEM (query): 0103 4100 0002 D037
Response from BEM: 0103 0400 0160 9E02 5B
Value Meaning
0103 0400 0160 9E... 01=Modbus address1
0103 0400 0160 9E... 03=Read holding registers function
0103 0400 0160 9E... 04=Response of BEM consists of 4 bytes:
00 0160 9E 1. Data bite 0 * 2
28
+ 0 * 2
24
= 0
00 0160 9E 2. Data bite 0 * 2
20
+ 1 * 2
16
= 65536
00 0160 9E 3. Data bite 6 * 2
12
+ 0 * 2
8
= 24576
00 0160 9E 4. Data bite 9 * 2
4
+ 14 * 2
0
= 158
The Modbus value therefore corresponds to the sum 90270
If the value of a data query for data address is 4186 = 2 (see tab. Data values number of decimal
places), the Modbus value bust be divided by 100. The result is then 902.7.
If the value of a data query for data address is 4015 = 5 (see tab. Data values unit total) The unit is
total galUS.
The end result for Total TA1 is therefore 902.7 galUS.
Notice The numbering of the register addresses starts at1, the data addressing at0. This is how e.g. when
reading register1 the data address0 is used.
Notice All units and the number of decimal places should be read out at least during initialization of the elec-
tronic unit, i.e. during switch-on, because these values can be modified manually.
Notice For parameter settings of the electronic unit via Modbus function 10(hex)=write holding registers (pre-
set multiple registers) can be used. Data exchange via the Modbus connection is not password-protec-
ted – avoid unintended overwriting of the total values or parameter addresses!
Notice All data can be read out or written in packages of up to 64words.
Reset of the total values via the Modbus:
o Command Reset Total consumptionT1: 0110 4002 0002 0400 0000 0043 B5
o Command Reset Total consumption 2: 0110 4004 0002 0400 0000 00C3 9F
5 Transportation, storage
5.1 Scope of delivery
The following components belong to the scope of delivery of the electronic unit:
o Operating instructions
o Password
o Work sheet
o Mounting frame with screws and wedge lock washers
o Terminal tool
o KRAL tool set
5.2 Unpacking and checking the state of delivery
Personnel qualification: o Trained personnel
1. Upon delivery check the product for damage during transportation.
2. Report damage during transportation immediately to the manufacturer.
3. Dispose of packing material in accordance with the locally applicable regulations.
Operating instructions
OIE 12en-GB Edition 2020-03
15
