11 Menu description
11.3 Menu1: Display
11.3 Menu1: Display
o Display of measured values
o Resetting the sum
o Setting contrast and background illumination
o Ä Operation,Page22
Menu item Description
1.00Information Shows the serial number as well as the version of software and hardware.
1.01Consumption
display
Displays the current consumption in the preset unit.
Note:
When the direction of rotation changes, the displayed rate value can vary strongly. Increase the
smoothing value, see 2.16Setting Averaging display.
1.02Display total Shows the total valuesT1 andT2 Shows the consumption since the last reset.
Note
Total value stops at the following minimum value or maximum value:
o With three decimal places:
+/-1999999.999
o With a decimal place:
+/-199999999,9
Decrease decimal places or change the unit Ä Troubleshooting,Page38.
1.03Display
VolumeterA
Shows flowQA and temperatureTempA . If the temperature lies outside the permissible range or if a
temperature sensor is not connected, "---,-" is displayed.
Note:
When the direction of rotation changes, the displayed rate value can vary strongly. Increase the
smoothing value, see 2.16Setting Averaging display.
1.04Display
VolumeterA Total
Shows the total valuesTA1 andTA2 of the flowmeterA since the last reset.
1.05Display Volu-
meterB
Shows flowQB and temperatureTempB . If the temperature lies outside the permissible range or if a
temperature sensor is not connected, "---,-" is displayed.
Note:
When the direction of rotation changes, the displayed rate value can vary strongly. Increase the
smoothing value, see 2.16Setting Averaging display.
1.06 Display
VolumeterB Total
Shows the total valuesTB1 andTB2 of the flowmeterB since the last reset.
1.07Filling amount Act.
Current dispatch amount
Nom.
Desired filling amount
Function
o Start
Beginning of filling. When the set filling amount is reached, filling is stopped automatically. After
three seconds waiting period a further start is possible.
o Stop
Interruption of dispatching before the set dispatch amount has been reached.
o Proceed
Dispatching is continued.
o Cancel
Dispatching is aborted. Start is displayed and a new dispatching process can be started.
Requirement:
3.13Setting function relay1 Set to Filling .
1.08Display direction
change VolumeterA
Shows the number of the flow direction changes of the flowmeterA since the last reset.
Requirement:
2.13Setting Function pulse inputs Set to Encoder .
Note:
The counter can be increased in case of a power failure even without change of direction. Recom-
mendation: Reset the counter before starting the measurement.
