Kreg 720PRO - Mount the Dock Adapters to a Work Surface

9
3
Optional: Mount the Dock Adapters to a Work Surface
If desired, you can mount the dock adapters to your work surface for added stability.
a. Place the docking station (with the 700-Series Jig attached to it) in the desired
position on your workbench.
b. Drive one Kreg pocket-hole screw (1) through each of the four mounting holes (2)
in the dock adapters (H).
Note You can use Kreg SML-C125 screws or any other Kreg pocket-hole screw.
H
1
2
