INSTALLATION
2
13
OPTISONIC 3400
www.krohne.com02/2015 - QS OPTISONIC 3400 - 4002741204-R04 en
2.9 Bends
2.10 Open feed or discharge
Install meter on a lowered section of the pipe to ensure a full pipe condition through the meter.
Figure 2-9: Installation in bending pipes
Figure 2-10: Installation in bending pipes
Figure 2-11: Open discharge
