2 INSTALLATION
16
OPTISONIC 3400
www.krohne.com 02/2015 - QS OPTISONIC 3400 - 4002741204-R04 en
2.15 Mounting
2.16 Flange deviation
2.17 Mounting position
CAUTION!
Max. permissible misalignment of pipe flange faces: M
max
0.5 degree,
accoording ASME B16.5 Individual flanges. See Appendix 12 ; Flange face aligment of the
General Piping Requirements DEP 31.38.01.11-GEN
Figure 2-16: Flange deviation
1 M
max
Figure 2-17: Horizontal and vertical mounting
