4.1 Dimensions and weights
4.2 Variants
For all dimensions and options; see tables on next pages (tables not final)
Note; the cCSA versions ( DN25...65 / 1...2.5") are manufactured with a heavy duty neck (SS)
which is 3.6 mm / 0.14 inch higher.
Remote version
Remote versionRemote version
Remote version a = 88 mm / 3.5"
b = 139 mm / 5.5" 1
c = 106 mm / 4.2"
Total height = H + a 2
Compact version
Compact versionCompact version
Compact version a = 155 mm / 6.1"
b = 230 mm / 9.1" 1
c = 260 mm / 10.2"
Total height = H + a 2
1 The value may vary depending on the used cable glands.
2 The value depends on version
Standard version and
Standard version and Standard version and
Standard version and
Extended temperature -
Extended temperature - Extended temperature -
Extended temperature -
High Viscosity -
High Viscosity - High Viscosity -
High Viscosity -
Cryogenic versions;
Cryogenic versions;Cryogenic versions;
Cryogenic versions;
≤ DN300 / 12"
DN300 / 12" DN300 / 12"
DN300 / 12"
DIN: L= 250...500 mm /
9.8"...19.7"
ANSI: L= 250...500 mm /
9.8"...19.7"
* for Cryo - HV - XXT
versions;
ANSI: L= 250...550 mm /
9.8"...21.7"
Standard version;
Standard version;Standard version;
Standard version;
≥ DN350 / 14"
DN350 / 14" DN350 / 14"
DN350 / 14"
DIN: L= 500..600 mm /
19.7"...23.6"
ANSI: L= 700...800 mm /
27.6"...31.5"
Extended temperature -
Extended temperature - Extended temperature -
Extended temperature -
High Viscosity -
High Viscosity - High Viscosity -
High Viscosity -
Cryogenic version;
Cryogenic version; Cryogenic version;
Cryogenic version;
≥ DN350 / 14"
DN350 / 14" DN350 / 14"
DN350 / 14"
DIN: L= 500...750 mm /
19.7"...29.5"
ANSI: L= 700...850 mm /
27.6"...33.5"
