TECHNICAL DATA 4
35
OPTISONIC 3400
www.krohne.com02/2015 - QS OPTISONIC 3400 - 4002741204-R04 en
EN1092-1; Extended temperature - High Viscosity and Cryogenic (SS) version - PN16
EN1092-1; Extended temperature - High Viscosity and Cryogenic (SS) version - PN10
Nominal
size
Dimensions [mm] Approximate weight
[kg]
DN L H W Di CS Di SS CS SS
100 350 261 220 104 104 23 23
125 350 287 250 130 130 29 29
150 350 319 285 158 158 38 38
200 450 409 340 207 207 49 49
250 500 469 405 260 260 67 68
300 500 520 460 310 310 82 82
Nominal
size
Dimensions [mm] Approximate weight
[kg]
DN L H W Di CS Di SS CS SS
200 450 409 340 207 207 50 50
250 500 512 445 260 260 66 66
300 500 512 445 310 310 75 75
350 500 559 505 342 342 91 91
400 600 594 565 393 393 114 114
450 600 674 615 443 443 130 130
500 650 722 670 494 494 151 151
600 700 824 780 594 594 195 195
700 750 929 895 694 3 280 3
800 900 1039 1015 794 3 380 3
900 900 1137 1115 889 3 469 3
1000 1000 1247 1230 991 3 595 3
3 TBD - Consult KROHNE for more information
