IV - 9
Handling the swather when in use
Before starting any transport journeys,
pressurize the deployment arm hydraulic
cylinders and then set the tractor hydrau-
lics to "neutral", so that the deployment
arm transport locks are not loaded.
939 486-2
4.4.4 Securing the tine tips (transport
position and parked swather)
Tines that are located below 2 m when the machine is in
transport position or parked, must be secured with a tine
guard. The tine guards are located on the front and
centre hoop guards of the rotors.
• Plug the tine guards (1) onto the tine.
Never move the rotors from working to
transport position while the machine is
operated across a slope.
4.4.5 Driving in sloping
KS102325
