V - 1
Basic setting
5.1 Height of the tractor lower link
arms
The height of the tractor lower link arms should be set so
that the lower link arm pins are
H approx. 80 cm
above the ground.
Fix the lower link arms at this height.
(see also Point 8.2)
Keep a safe distance from the swather
disk when it's turning! Before switching
on the PTO shaft, ensure that no-one
could be caught by the swather disk.
When the PTO shaft is running, the
swather arms may only be raised to
just before their stops.
5 Basic setting
The basic setting should be undertaken on even
surfaces.
H
SW101025
