VII - 2
Lubrication
7.3 Lubricant quantities and designations for the gearboxes
Bio-lubricants
Volume ltr. Name/Brand Oil change Name/Brand
Swather disk gearbox 0,5 Flowing gearbox grease Service life
GFO 35 grease lubricated
Pass-through gearbox 1,7 SAE 90 about 1000 ha.
on request
Front 2x0,7 SAE 90
drive gear
about 1000 ha.
Rear 2x0,7 SAE 90
drive gear
about 1000 ha.
7.4 Pass-through gearbox
Oil inspection: • Intervals see section 7.3
• Remove check screw (1)
• Oil level up to bore hole
• If necessary, top up oil (SAE 90), fit
check screw (1)
Oil change: • Intervals see section 7.3
• Unscrew the oil draining screw (2)
• Collect the used oil in a suitable
collection vessel.
• Fit oil draining screw(2)
• Fill oil (3) (Oil level up to bore hole (1))
Oil quality: see section 7.3
Tank capacity: see section 7.3
The used oil must be correctly
disposed of!
SW101028
2
3
1
