Chapter 4 Maintaining the Timeclock
4-30 ADP, Inc.
12. Position the transformer back into place behind the wire clip, route the cable
back to its connection on the main board, and plug in the cable.
Number Description
1 Transformer cable
2 Hooks for routing the cable
3 Transformer connection to the main board (DC power)
To Next Page
