Submersible motor pumps (100 mm)
11
9.2 Pump - CORA 18C (Mix flow)
931 Washer
920 Nut
914.03 Screw (Chease head)
914.02 Screw (Allen head)
914.01 Screw (round head)
901 Bolt
849 Sleeve coupling
825 Cable protection pipe
759 Valve dish with ‘O’ ring
752 Valve seat
751 Valve body
529.02 Bearing sleeve (last)
529.01 Bearing sleeve (intermediate)
525 Spacer sleeve
521 Stage sleeve
500 End ring with wearing ring (502)
411 Gasket
384 Thrust bearing plate
382.03 Bearing body w/o bearing bush
382.02 Bearing body with bearing bush
382.01 Intermediate bearing body with brg. bush
230 Impeller
211 Pump shaft
143 Suction strainer
131 Inlet ring
112 Stage bowl
109 Stage pipe
106 Suction casing
81-29 Cable clamp
10-6 Pump jacket
Part no. Description
