Submersible motor pumps (100 mm)
7
5 Maintenance
5.1 Storage
Prior to delivery, submersible motors are generally preserved and stored up to 1 year.
Always store the motor in upright position protected from dust and frost.
6 Services
Do not attempt to open the motor / pump for repair that will render our warranty null & void.
Please take up with Authorised Service Center or to the concerned dealer.
Unauthorized repaires are not permitted since they cause poor performance and shorter life of the pumpset.
7 Recommended stock of spare parts for 2 years of continuous operation
Part No. Description
No. of pumps (including Standby Pumps)
2 3 4 5 6 8 10 or more
271 Sand Guard 1 2 3
384 Thrust Bearing Plate 1 2 3
412.01,02 O Ring 2 2 3
421 Oil Seal 2 3 4 sets
828 Cable Packing Ring 1 2 2 3
829 Cable Gland Ring 1 2 2 3
849 Coupling 1 1
912/913 Vent plug & Drain plug 1 1 1
932 Circlip 1 2 3
