Submersible motor pumps (100 mm)
9.6 Motor - UMT (S) 100
15
920 Nut
914 Cheese head screw
904.52 Threaded pin
818 Rotor
817 Can
813 Stator packet
580 Sand cap guard
560.52 Thrust pin
550.53 Washer
550.52 Disc
550.51 Disc
545.52 Bearing bush (upper)
545.51 Bearing bush (lower)
421 Oil seal
412.53 O ring
412.52 O ring
412.51 O ring
387 Thrust bearing segment
384.52 Counter thrust bearing plate
384.51 Thrust bearing plate
382.52 Bearing body (upper)
382.51 Bearing body (lower)
271 Sand guard
160 Cover
81-96.53 Cable connector (female)
81-96.52 Cable connector (male)
81-78 Stator pipe
81-59 Stator
81-27.52 End disc (upper)
81-27.51 End disc (lower)
59-6 Ball
32-2 Ball retainer
Part no. Description
