Submersible motor pumps (100 mm)
12
9.3 Pump - CORA 2AH, 3AH & 3A (Radial flow)
931 Washer
920 Square nut
914.03 Screw (Chease head)
914.02 Screw (Allen head)
914.01 Screw (Round head)
901 Hex. head bolt
759 Valve dish with O-ring
752 Valve seat
751 Valve body
543 Spacer bush
529 Bearing sleeve
411 Gasket
384 Thrust ring
382 Intermediate bearing body with bush
232 Impeller
211 Pump shaft
143 Suction strainer
131 Inlet ring
108 Stage casing
106 Suction casing
81-29 Cable clamp
10-6 Pump jacket
Part No. Description
