Submersible motor pumps (100 mm)
9.4 Motor - UMA 100
13
914.05 Screw (Allen head)
914.04 Screw (Allen head)
914.03 Screw (Allen head)
914.02 Screw (Chease head)
914.01 Screw (Allen head)
904 Threaded pin
829 Cable pressure washer
828 Cable gland ring
818 Rotor
580 Sand cap guard
562 Cylindrical pin
550 Disc
421 Oil seal
392 Bearing segment carrier
389 Counter thrust bearing ring
387 Thrust bearing segement
384 Thrust bearing plate
382.02 Bearing body upper
382.01 Bearing body lower
342 Thrust bearing lantern
271 Sand guard
160 Cover
132.52 Intermediate part (Upper)
132.51 Intermediate part (Lower)
81-77 Balancing ring
81-74 Pressure Nut
81-59 Stator with winding
81-34 Finger pressure disc
59-12 Diaphragm
Part no. Description
