Submersible motor pumps (100 mm)
16
9.7 Motor - XUMA (S) 100
932 Circlip
931 Washer
920.02 Hex. nut
920.01 Hex. domed cap nut
914.02 Slotted cheese head screw
914.01 Allen head bolt
904 Threaded pin
903.01,02 Plug (Water filling / Water drain)
902.02 Stud (M8x56.6)
902.01 Stud (M6x97)
829 Cable pressure washer
828 Cable gland ring
818 Rotor with balancing ring (81-77)
720 Double nipple
580 Sand guard cap
550 Washer
500.02 Ring - upper
500.01 Ring - lower
421 Oil seal
411.01,02 Gasket
392 Bearing segment carrier
389 Counter thrust ring
387 Thrust bearing segment
384 Thrust plate assembly with disc (550)
382.02 Beaing body upper with bush (545.02)
382.01 Bearing body lower with bush (545.01)
354 Thrust bearing housing
271 Sand guard
160 Cover
81-74 Pressure nut
81-59 Stator with inter part (132)
81-18 Cable shoe
59-33 Storage tank
59-12 Diaphragm
Part No. Description
