9 Related Documents
64 of 76
CTN / CTN-H
Part No. Description Scope of supply
320.02 Angular contact ball
bearing
341 Drive lantern with disc 550.69, guard 680.01, hexagon head bolt 901.69, stud 902.11,
hexagon nut 920.11
344 Bearing bracket lantern with bearing cover 360.02, lip seal 421.03/.04, hexagon head bolt
901.37
27)
, studs 902.06, socket head cap screw 914.02, hexagon nut
920.06
350.04 Bearing housing with O-ring 412.10
27)28)
, bearing bush 545.03, grooved pin 561.22, grub
screw 904.12
421.03/.04 Lip seal
451.02 Stuffing box housing with joint ring 411.33
27)28)
/.34
27)28)
/.47, disc 550.02, stud 902.09, screwed
plug 903.33
27)28)
/.34
27)28)
, hexagon nut 920.09
452.02 Gland follower
454.02 Stuffing box ring
458.02 Lantern ring
461.02 Gland packing
502.01/.02 Casing wear ring
27)
with grooved pin 561.01
27)28)
/.06
27)28)
, grub screw 904.03
27)28)
/.04
27)28)
502.03/.04 Casing wear ring
27)29)
with grooved pin 561.07
27)28)
/.08
27)28)
, grub screw 904.34
27)28)
/.35
27)28)
524.02 Shaft protecting
sleeve
27)
with O-ring 412.32, grub screw 904.14
525 Spacer sleeve
29)
529.01/.03
27)
Bearing sleeve with grooved pin 561.18/.19
27)
or screw 900.18/.19
27)
529.02 Bearing sleeve
545.01 Bearing bush
545.02/.03 Bearing bush
27)
550.21 Set of spacer discs
71-9.01 Pipe assembly
31)
with gasket 400.18, hexagon head bolt 901.29, hexagon nut 920.29
71-9.02 Pipe assembly
31)
with gasket 400.17, hexagon head bolt 901.32, hexagon nut 920.32
72-1 Flanged bend with gasket 400.17
852.01 Threaded coupling
893.02 Soleplate with joint ring 411.47, disc 550.17, eyebolt 900.03, studs
902.05/.12/.30/.31, hexagon nuts 920.05/.12/.30/.31
31) 71-9.01/.02/.03 etc. for several pipe assemblies, counted from the pump
