9 Related Documents
67 of 76
CTN / CTN-H
Part No. Description Scope of supply
529.01/.03 Bearing sleeve with grooved pin 561.18/.19 or screw 900.18/.19 or grub screw
904.11/.12
529.02 Bearing sleeve
545.01 Bearing bush
545.02/.03 Bearing bush with grooved pin 561.21 (for 545.03)
550.21 Set of spacer discs
71-9.01 Pipe assembly with gasket 400.18, hexagon head bolt 901.29, hexagon nut 920.29
71-9.02 Pipe assembly with gasket 400.17, hexagon head bolt 901.32, hexagon nut 920.32
710.23-.26 Pipe with pipe union 731.18/.37/.38/.39/.40/.41
72-1 Flanged bend with gasket 400.17
852 Threaded coupling
893.02 Soleplate with disc 550.17, eyebolt 900.03, studs 902.05/.12/.30/.31, hexagon nuts
920.05/.12/.30/.31
