KSB PumpDrive - Page 112

Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-2-3-1 Active Set-up
Display of current
setup
1 1 - - - All Setup 1
Setup 2
3-2-3-2 Set-up Version
Setup version
1 1 0 99.99 - Customer -
3-3 Load and Motor
Load and motor
3-3-1 V/f Settings
Submenu for
displaying V/f
settings
- - - - - - -
3-3-1-1 V/f Voltage 0
Selection of V/f
voltage 0
2 2 0 15 % Customer -
3-3-1-2 V/f Frequency 1
Selection of V/f
voltage 1
4 4 0 100 % Customer -
3-3-1-3 V/f Frequency 1
Selection of V/f
frequency 1
20 20 0 100 % Customer -
3-3-1-4 V/f Voltage 2
Selection of V/f
voltage 2
16 16 0 100 % Customer -
3-3-1-5 V/f Frequency 2
Selection of V/f
frequency 2
40 40 0 100 % Customer -
3-3-1-6 V/f Voltage 3
Selection of V/f
voltage 3
64 64 0 100 % Customer -
3-3-1-7 V/f Frequency 3
Selection of V/f
frequency 3
80 80 0 100 % Customer -
3-3-1-8 V/f Voltage 4
Selection of V/f
voltage 4
100 100 0 100 % Customer -
3-3-1-9 V/f Frequency 4
Selection of V/f
frequency 4
100 100 0 100 % Customer -
3-3-2 Motor Data
Submenu for
displaying motor
data
- - - - - - -
3-3-2-1 Rated Power
Selection of motor
nominal power
bg bg 0.55 45 kW Customer -
3-3-2-2 Rated Voltage
Selection of nominal
motor voltage
bg bg 342 528 V Customer -
3-3-2-3 Rated Freq
Selection of nominal
motor frequency
bg bg 45 65 Hz Customer -
3-3-2-4 Rated Current
Selection of nominal
motor current
bg bg 0.1 999 A Customer -
3-3-2-5 Rated Speed
Selection of nominal
motor speed
bg bg 300 3600 rpm Customer -
3-3-2-6 Rated Cosphi
Selection of nominal
motor cos phi
bg bg 0.1 0.99 - Customer -
