Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-3-7 Res Freq Bypass
Submenu for
displaying resonant
frequencies
- - - - - - -
3-3-7-1 Lo Bypass Freq
Limit to prevent
resonant frequency
0 0 0 3-3-7-2 % Customer -
3-3-7-2 Hi Bypass Freq
Limit to prevent
resonant frequency
0 0 3-3-7-1 100 % Customer -
3-4 Spec Pump Settg
Menu for special pump settings
3-4-1 Q/p Measurement
Submenu for
measurement of
flow rate Q and
pressure p
- - - - - - -
3-4-1-1 Flow Rate Meas
Measurement/
estimation of flow
rate Q
1 1 - - - Customer Estimated
Measured
3-4-1-2 Q 100% Value
Selection of flow
rate value for Q
measurement/
estimation
0 0 0 9999 3-2-2-2 Customer -
3-4-1-3 p 100% Value
Selection of pressure
value for Q
measurement/
estimation
0 0 0 9999 3-2-2-3 Customer -
3-4-2 Setpoint Comp
Submenu for
pressure/differential
pressure control
with dynamic
pressure setpoint
compensation
- - - - - - -
3-4-2-1 Q Compensation
Selection of flow
rate value for
dynamic pressure
setpoint
compensation
100 100 0 100 % Customer -
3-4-2-2 Setpoint-Comp
Setpoint
compensation for
dynamic pressure
compensation
0 0 0 9999 3-2-2-1 Customer -
3-4-3 Sleep Mode
Submenu for sleep
mode
- - - - - - -
3-4-3-1 Sleep Mode
Activate/deactivate
sleep mode
1 1 - - - Customer Disabled
Enabled
3-4-3-2 Diff to Restart
Selection of
feedback and
setpoint to start
0 0 0 9999 3-2-2-1 Customer -
10 Parameter lists
