Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-4-3-3 Start Delay
Selection of time
delay for start
1 1 0.1 60 s Customer -
3-4-3-4 Freq Stop Lim
Limit value of
frequency
60 60 3-6-1-2 3-6-1-3 % Customer -
3-4-3-5 Stop Cnd Tm
Selection of time
delay for stop
10 10 0.1 60 s Customer -
3-4-3-6 Low Q Det Tm
Detection of
minimum flow rate
Q
60 60 45 360 s Customer -
3-4-3-7 Diff Start Puls
Selection of
feedback and
setpoint to start test
pulses
2 2 0 9999 3-2-2-1 Customer -
3-4-3-8 Pulse Ampl
Selection of pulse
amplitude
2 2 0 9999 3-2-2-1 Customer -
3-4-3-9 Pulse Time
Selection of pulse
time
10 10 3 30 s Customer -
3-5 Setpoint
Menu for setpoint
3-5-1 General Settngs
Submenu for
general setpoint
settings
- - - - - - -
3-5-1-1 Setpoint Scale
Scale of setpoint
1 1 0.5 2 - Customer -
3-5-1-2 Min Setpoint
Specification of
minimum setpoint
0 0 0 3-5-1-3 3-2-2-1 Customer -
3-5-1-3 Max Setpoint
Specification of
maximum setpoint
100 100 3-5-1-2 9999 3-2-2-1 Customer -
3-5-1-4 Control Mode
Control mode
2 2 - - - Factory OFF
Auto
Manual
3-5-2 Preset Setpoint
Submenu for
configurable
setpoint
- - - - - - -
3-5-2-1 Preset Setpoint
Configurable
setpoint
0 0 3-5-1-2 3-5-1-3 3-2-2-1 All -
3-5-2-2 Prset Setp Step
Increment/
decrement for
setpoint frequency
in manual mode
0.1 0.1 0 9999 3-2-2-1 Customer -
3-5-3 Prset OutFrq
Fixed frequency
submenu, selection
via digital inputs
- - - - - - -
3-5-3-1 Preset OutFrq 1
Fixed frequency,
selection via digital
inputs
100 100 0 100 % Customer -
10 Parameter lists
