Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-5-3-2 Preset OutFrq 2
Fixed frequency,
selection via digital
inputs
75 75 0 100 % Customer -
3-5-3-3 Preset OutFrq 2
Fixed frequency,
selection via digital
inputs
50 50 0 100 % Customer -
3-5-3-4 Preset Man Out
Selection of output
frequency in manual
mode
0 0 0 100 % Customer -
3-5-4 Setpoint Source
Submenu for
displaying the
source of the
setpoint
- - - - - - -
3-5-4-1 Setp Source 1
Selection of source
of setpoint 1
2 2 - - - Customer None
Analog IN 1
Analog IN 2
Configurable
Setpoint
Remote Setpoint
RS232 Setpoint
3-5-4-2 Setp Source 2
Selection of source
of setpoint 2
4 4 - - - Customer None
Analog IN 1
Analog IN 2
Configurable
Setpoint
Remote Setpoint
RS232 Setpoint
3-5-4-3 Setp Source 3
Selection of source
of setpoint 3
5 5 - - Customer None
Analog IN 1
Analog IN 2
Configurable
Setpoint
Remote Setpoint
RS232 Setpoint
3-6 Limits & Warns
Menu for limit values and warnings
3-6-1 Motor Limits
Submenu for
displaying the limit
value of the motor
- - - - - - -
3-6-1-1 Direc Mot rot
Selection of the
direction of rotation
of the motor
1 1 - - - Customer Clockwise
Anti-clockwise
3-6-1-2 Frequency Lo
Selection of lower
limit value for
motor frequency
50 50 0 3-6-1-3 % Customer -
3-6-1-3 Frequency Hi
Selection of upper
limit value for
motor frequency
100 100 3-6-1-2 100 % Customer -
3-6-1-4 MotMod Curr Lim
Selection of motor
mode current limit
75 75 50 100 % Customer -
10 Parameter lists
