Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-6-1-5 GenMod Curr Lim
Selection of
generator mode
current limit
30 30 0 100 % Factory -
3-6-2 Motor Warnings
Submenu for motor
warnings
- - - - - - -
3-6-2-1 Lo Curr Wrn Lim
Selection of lower
limit value for
current monitoring
0 0 0 3-6-2-2 % Customer -
3-6-2-2 Hi Curr Wrn Lim
Selection of upper
limit value for
current monitoring
100 100 3-6-2-1 100 % Customer -
3-6-2-3 Curr Wrn Tm Dly
Selection of time
delay for current
monitoring
5 5 0 60 s Customer -
3-6-2-4 Curr Wrn Fnc
Current monitoring
function
1 1 - - - Customer No Function
Warning
Stop & Trip
3-6-2-5 Lo Out Freq Wrn
Selection of lower
limit value for
frequency
monitoring
0 0 0 3-6-2-6 % Customer -
3-6-2-6 Hi Out Freq Wrn
Selection of upper
limit value for
frequency
monitoring
100 100 3-6-2-5 100 % Customer -
3-6-2-7 Freq Wrn Tm Dly
Selection of time
delay of frequency
monitoring
5 5 0 60 s Customer -
3-6-2-8 Freq Wrn Fnc
Frequency
monitoring function
1 1 - - - Customer No Function
Warning
Stop & Trip
3-6-3 Analog IN Wrn
Settings for Analog
IN warnings
- - - - - - -
3-6-3-1 An IN 1 Low
Selection of lower
limit value for
analog input
monitoring
0 0 3-8-2-7 3-8-2-8 3-8-2-6 Customer -
3-6-3-2 An IN 1 High
Selection of upper
limit value for
analog input
monitoring
100 100 3-8-2-7 3-8-2-8 3-8-2-6 Customer -
3-6-3-3 An IN1 Wrn
TDly Time delay for
function
5 5 0 60 s Customer -
3-6-3-4 An IN 1 Wrn Fnc
Analog input
monitoring function
1 1 - - - Customer No Function
Warning
Stop & Trip
10 Parameter lists
