Table 129: Accessories – Mounting kit
Quantity Component Use Material
number
1 CAN bus cable, pre-
configured
Cable 2 x 2 x 0.22 mm²,
length approx. 1 m
01131429
1 Signal cable
5-core cable, halogen-free,
type Ölflex 110CH, length
approx. 1 m
01131430
1 Measuring resistor 500 Ohm Conversion of the 0/4 - 20 mA (current)
measurement signal of the differential
pressure sensor into 0/2 - 10 V DC voltage
values
01127044
2 Wire jumper Wiring of digital inputs DI1 and DI6 with
+24 V DC on both PumpDrives
01131428
3 Cable tie
1 PumpDrive DPM operating
manual
See
product
literature
12 Purchase Order Specifications
148 of 162
