Table 133: Accessories – Temperature measurement
Description Design Mat. No. [kg]
Resistance thermometer Pre-configured for measured medium
temperature of 0 to 150 °CTR10-C sensor
well, T24.10 transmitter and TW35-4
thermowell for measured medium
temperatures of -200 °C to 600 °C
Sensor tolerance: Class B to DIN EN 60751,
2-wire output 4 - 20 mA, Measuring range
with PT100 element 1 x 3-wire, Supply
voltage: 10 - 36 V DC, G1/2B process
connection made from CrNi steel 1.4571,
Total length with stem: 255 mm,
Thermometer installation length: 110 mm,
Connecting head type BSZ, aluminium,
IP65 enclosure
01149295 0.8
Table 134: Accessories – Flow measurement
Description Design Mat. No. [kg]
Flow sensor 3 … 300 cm/s
For filter loss compensation control, cost-
effective flow control,
Measuring range 3 - 300 cm/s, process
connection with internal thread, output
4 - 20 mA
01150960 0.3
Plug connector with cable
for Effector 300 transmitter
Cable socket M12/angled/4-core/MS, 0
LED/5m/PUR, Compatible with cable drag
chains, Free of halogen and silicone
01473177 0,2
Table 135: Accessories – Connection cables
Description Design Mat. No. [kg]
Connection cable for sensors Cable 2 x 2 x 0.5 mm², shielded, for
connecting sensors to PumpDrive, price
per metre
01083890 0.1
Connection cable for
redundant sensor
connection
5-core cable, halogen-free, type Ölflex
110CH, length approx. 1 m, Pre-
configured, for forwarding a sensor signal
to the second PumpDrive for redundant
operation (e.g. DPM)
01131430 0.3
12 Purchase Order Specifications
154 of 162
