Parameter Description Possible settings Factory setting
3-6-3-3 Analog input 1 time
delay
0..60 (s)
Access: Standard
5 s
3-6-3-4 Function
Analog input 1 –
Monitoring
1 - No Function
2 - Warning
3 - Stop and Trip
1 - No Function
3-6-3-5 Lower limit
Analog input 2
Analog IN 2 Low (3-8-3-7) to Analog IN
2 High (3-8-3-8) in Analog IN 2 Unit
(3-8-3-6)
0
3-6-3-6 Upper limit for analog
input 2
100
3-6-3-7 Analog input 2 time
delay
0..60 (s)
Access: Standard
5 s
3-6-3-8 Function
Analog input 2 –
Monitoring
1 - No Function
2 - Warning
3 - Stop and Trip
1 - No Function
3-8-2-6 Unit of Analog IN 1 Selection list III (⇨ Section 10.1 Page
129)
1
3-8-2-7 Low value for Analog
IN 1
0 to Analog IN 1 High (3-8-2-8) in
Analog IN 1 Unit (3-8-2-6)
0
3-8-2-8 High value for Analog
IN 1
Analog IN 1 Low (3-8-2-7) to 9999 in
Analog IN 1 Unit (3-8-2-6)
100
3-8-3-6 Unit of Analog IN 2 Selection list III (⇨ Section 10.1 Page
129)
1
3-8-3-7 Low value for Analog
IN 2
0 to Analog IN 2 High (3-8-3-8) in
Analog IN 2 Unit (3-8-3-6)
0
3-8-3-8 High value for Analog
IN 2
Analog IN 2 Low (3-8-3-7) to 9999 in
Analog IN 2 Unit (3-8-3-6)
100
Table 84: Parameters for monitoring the setpoint and actual value
Parameter Description Possible settings Factory setting
3-6-5-1 Lower limit
Setpoint monitoring
0 to Maximum Setpoint (3-5-1-3) in
physical setpoint unit (3-2-2-1)
0
3-6-5-2 Upper limit
Setpoint monitoring
Minimum Setpoint (3-5-1-2) to 100 in
physical setpoint unit (3-2-2-1)
100
3-6-5-3 Time delay
Setpoint monitoring
0..60 (s) 5 s
3-6-5-4 Setpoint warning
function
1 - No Function
2 - Warning
3 - Stop and Trip
1 - No Function
3-6-6-1 Lower limit
Actual value
monitoring
0 to Feedback High Limit (3-6-6-2) in
physical setpoint unit (3-2-2-1)
0
3-6-6-2 Upper limit
Actual value
monitoring
Feedback Low Limit (3-6-6-1) to 9999 in
physical setpoint unit (3-2-2-1)
100
3-6-6-3 Time delay
Actual value
monitoring
0..60 (s) 5 s
3-6-6-4 Actual value
monitoring function
1 - No Function
2 - Warning
3 - Stop and Trip
1 - No Function
3-5-1-2 Lower limit
Setpoint monitoring
0 to Maximum Setpoint (3-5-1-3) in
physical setpoint unit (3-2-2-1)
0
3-5-1-3 Upper limit
Setpoint monitoring
Minimum Setpoint (3-5-1-2) to 9999 in
physical setpoint unit (3-2-2-1)
100
3-2-2-1 Physical unit of setpoint Selection list III (⇨ Section 10.1 Page
129)
Access: Service
1
7 Commissioning/shutdown
