7.2.4.1.2 Parameterisation of the dynamic pressure setpoint compensation function
on PumpDrive Advanced
If the dynamic pressure setpoint compensation function is to be used in a multiple
pump configuration, ensure that the maximum number of pumps running
simultaneously
3-12-5-1
is set properly to match requirements (⇨ Section 7.1.3 Page
62) .
The following parameters are required for parameterisation of the dynamic pressure
setpoint compensation function on a PumpDrive Advanced model using flow rate
estimation based on the speed or the power:
Table 89: Parameters for the dynamic pressure setpoint compensation function on a PumpDrive Advanced model
using flow rate estimation based on the speed
Parameter Description Possible settings Factory setting
3-2-2-1
Physical unit of setpoint Selection list III (⇨ Section 10.1 Page
129)
1
3-2-2-2
Physical unit of flow
rate (Q)
29
3-2-2-3
Physical unit of pressure 1
3-9-1-5
Process type of PI
controller
Constant Pressure
Variable Pressure
Constant Flow
Other Setpoint
Constant Pressure
3-4-1-1
Q measurement/
estimate
Estimated
Measured
Estimated
3-12-1-1
Q measurement Measured
P/Q calculated
Measured
3-4-1-2
Calibration for Q
measurement
Q 100 % value
0 - 9999 in Q unit
(3-2-2-2)
(physical
unit of flow rate)
0
3-4-1-3
Calibration for Q
measurement
p 100 % value
0 - 9999 in physical unit of pressure
(3-2-2-3)
0
3-4-2-1
Q compensation point 0..100 (%) 0 %
3-4-2-2
Setpoint compensation 0 - 9999 in physical unit of setpoint
(3-2-2-1)
0
The parameters for setting the dynamic pressure setpoint compensation function on
a PumpDrive Advanced model using flow rate estimation based on the speed must be
configured as follows:
Table 90: Parameterisation for the dynamic pressure setpoint compensation function on a PumpDrive Advanced
model using flow rate estimation based on the speed
Parameter Description Settings
3-9-1-5
Process type of PI controller Variable pressure
3-4-1-1
Q measurement/estimate Estimated
3-12-1-1
Q measurement Measured
3-4-1-2
Calibration for Q measurement, Q 100 % value Maximum flow rate as per pump characteristic
curve (Q
max
)
3-4-1-3
Calibration for Q measurement, p 100 % value Full-scale value of pressure/differential pressure
sensor
3-4-2-1
Q compensation point As required by system conditions
3-4-2-2
Setpoint compensation
Parameters
3-12-3-7
to
3-12-3-13
and parameters
3-12-3-21
to
3-12-3-27
for the
pump's P/Q curve must be set in accordance with for parameterisation of the dynamic
pressure setpoint compensation function on a PumpDrive Advanced model using
flow rate estimation based on the power. Also read the information provided in the
relevant section for parameterising the flow rate estimation function (⇨ Section
7.2.2.3.1 Page 80) . The parameters must be set as follows:
7 Commissioning/shutdown
PumpDrive
87 of 162
