CONTROLS 6
15
6.1 Clutch lever
S03879-10
(SUPER DUKE R)
Clutch lever
1
is fitted on the handlebar on the left.
S04768-10
(SUPER DUKE RR)
Clutch lever
1
is fitted on the handlebar on the left.
The clutch is activated hydraulically and adjusts itself automati-
cally.
6.2 Hand brake lever
S03880-10
(SUPER DUKE R)
The hand brake lever
1
is fitted on the right side of the han-
dlebar.
S04769-10
(SUPER DUKE RR)
The hand brake lever
1
is fitted on the right side of the han-
dlebar.
The front brake is engaged using the hand brake lever.
