21 TECHNICAL DATA 113

Piston rings 2 half keystone rings

X (upper edge of piston to upper edge of cylinder) 0… 0.10 mm (0… 0.0039 in)

Z (height of control flap) 48 mm (1.89 in)

Primary transmission 26:72

Clutch Multidisc clutch in oil bath/hydraulically activated

Gearbox 6-gear, claw shifted

Transmission ratio

First gear 14:32

Second gear 16:26

Third gear 20:25

Fourth gear 22:23

Fifth gear 25:22

Sixth gear 26:20

Ignition Contactless controlled fully electronic ignition with digital igni-

tion adjustment, type Kokusan

Spark plug NGK BR 7 ES

Spark plug electrode gap 0.60 mm (0.0236 in)

Starting aid Kick starter and electric starter

21.1.5 300 XC

Design 1-cylinder 2-stroke engine, water-cooled, with reed intake and

exhaust control

Displacement 293.2 cm³ (17.892 cu in)

Stroke 72 mm (2.83 in)

Bore 72 mm (2.83 in)

Exhaust valve - Beginning of adjustment 5,550 rpm

Exhaust valve - end of adjustment with red auxiliary spring 7,200 rpm

Exhaust valve - end of adjustment with yellow auxiliary spring 7,900 rpm

Exhaust valve - end of adjustment with green auxiliary spring 8,400 rpm

Crankshaft bearing 1 grooved ball bearing/1 roller bearing

Conrod bearing Needle bearing

Piston pin bearing Needle bearing

Pistons Aluminum cast

Piston rings 2 rectangular rings
