MAINTENANCE ON CHASSIS AND ENGINE 134
9.61Removing the seat
100041-10
– Pull the release hook back. Lift up the seat at the rear, pull it back and then remove
from above.
9.62Mounting the seat
100046-10
– Check parts for damage and wear. Replace damaged or worn parts.
– Hook the slot on the seat into the collar sleeve of the fuel tank, lower the rear of
the seat and slide the tab under the fuel tank .
